SPS Sintering System Manufacturer & Supplier

S series SPS System

What is Spark Plasma Sintering

Spark Plasma Sintering “SPS” (aka FAST or Field Assisted Sintering Technology) is an advanced technique to take powder and turn it into solid parts similar to additive manufacturing but without having to melt the material. It allows for the rapid application of temperature and pressure via high-density pulsed current within a controlled atmosphere. The unique heating mechanism of using electrical current gives SPS the ability to consolidate materials that traditional processes can’t and at much faster rates. SPS is the ideal consolidation and bonding method for all of your materials including metals, refractory alloys, nanomaterials, ultra-high temp ceramics, and more. In simple terms, SPS can be thought of as a way of making strong and dense materials from powders using high heat and pressure.

Spark plasma sintering furnace has a maximum temperature of 1600℃. It can be used for material annealing, material thermocompression bonding, surface treatment and synthesis, etc. The treated sample can be metal, ceramic, nano material, amorphous material, and the like. It is perfectly fit solid electrolyte and electric thermal material

Benefits of SPS Sintering System

● Shorter Cycle Times - Sintering cycles are minutes vs hours/days for conventional processes. High productivity, extremely rapid material development capabilities.

● Lower Sintering Temperatures - Sinter materials at lower temperatures compared to conventional sintering processes

● Extremely Versatile - Densify low melting point metals, ultra-high temperature ceramics, or even bond dissimilar materials requiring nonuniform temperature. No other sintering process can come close. Can sinter porous parts and fully dense parts.

● High-precision process control - Able to finely control sintering parameters including temperature and pressure to ensure the best outcome for your parts. Unique chemistries are unable to be made with conventional liquid melt processes. Engineered structures within materials preserved that would otherwise be lost in other processes

Applications of SPS Sintering System

● Energy Storage: High-capacity lithium-ion batteries and other advanced energy storage materials

● Biomedical Engineering: Porous ceramics for drug delivery and scaffolds for tissue engineering

● Advanced Ceramics: High-temperature superconductors and high-performance piezoelectric ceramics

● Intermetallics: Advanced alloys with improved mechanical, thermal, and electrical properties

● Composites: Reinforced ceramics and metals with enhanced mechanical properties

Materials for SPS processing

Metals	Virtually any metals possible: Fe, Cu, Al, Au, Ag, Ni, Cr, Mo, Sn, Ti, W, Be
Ceramics	Oxides Carbides Nitrides Borides Flourides	Al2O3, Mulite, ZrO2, MgO, SiO2, TiO2, HfO2 SiC, B4C, TaC, TiC, WC, ZrC, VC Si3N4, TaN, TiN, AiN, ZrN, VN TiB2, HfB2, LaB6, ZrB2, VB2 LiF, CaF2, MgF2
Cermets	Si3N4+Ni, Al2O3+Ni, ZrO2+Ni Al2O3+TiC, SUS+ZrO2, Al2O3+SUS SUS+WC/Co, BN+Fe. WC+Co+Fe
Intermetalic compounds	TiAl. MoSi2, Si3Zr5,NiAl NbCo, NbAl, LaBaCuSO4, Sm2Co17
Other materials	Organic materials (polyimide, etc.), compositematerials

SPS Sintering System Manufacturer & Supplier | Haoyue

Haoyue is a leading manufacturer and supplier of SPS Sintering Systems, providing high-quality, reliable solutions for advanced material processing. Our company has been focusing on four major fields: advanced ceramics and composite materials, semiconductor materials, carbon materials, and lithium battery materials. The company has accumulated rich industry experience and patented technology, dedicated to serving customers and providing complete integrated industrial solutions.

For further enquiries, please contact us online.
